Found 182 results

  1. I have a 2008 edge limited I purchased in May and now have the darndest thing happen with my liftgate. The first issue was when I would use any button to open the liftgate it would open, ding 3 times and then start to automatically close. It wouldn't do this all the time, but frequently. I read to try to reset it by opening and then closing manually. This would periodically work, but it always happened again. Now, however, the power feature is not working at all. Power liftgate is "on" from the instrument panel. When I push any of the buttons it "clicks" like it is enagaging but it never opens. I have to open it manually and it has a lot of resistance. Once manually opened it will not stay open it wants to fall back closed right away. My head has been in the way several times so needless to say I want to get this issue resolved ASAP.
  2. I have a 2016 MKX that I believe has a bad rear mirror motor. I have purchased the new motor, but need advice removing the mirror glass to access the mirror motor. I have searched everywhere, but have only found a video that essentially forces the mirror off by reaching behind it and pulling on some clips. I can't really get my fingers behind the mirror glass, and am afraid to force it off the clips for fear of breaking the glass, which is available but very expensive. Does anyone have advice on how to remove the mirror glass to get access to the motor?
  3. SSM 47398 – 2015-2018 Edge Vehicles – 2.0L EcoBoost With 6F35 Transmission – Rattle Noise From Engine Flex Plate Some 2015-2018 Edge vehicles equipped with a 2.0L EcoBoost and 6F35 transmission may exhibit a rattle noise from the transmission bellhousing area while running. This may be the result of a cracked engine flexplate. When replacing the flexplate, lubricate the torque converter pilot hub with Multi-Purpose Grease XL-5-A (ESB-M1C93- before reassembling. Make sure the transmission locator dowel pins are correctly installed. If the dowel pins were pulled out of the engine block, new dowel pins will need to be installed in the engine block. Failure to do so could result in a repeat repair. Refer to Workshop Manual (WSM), Section 307-01A. Engineering is investigating, monitor OASIS for updates. To assist with the investigation use the Report a Vehicle Concern link at the bottom of the OASIS report and fill out the form. APPLICABLE VEHICLES 2015 – 2018 CAR: DQ CD539N EDGE
  4. Dehcure82

    20” rims and tires SOLD!

    Selling (4) 20" Lexani Wheels Gravity Black with CNC Accents Rims 5x108 bolt pattern center bore 63.4 mm With nitto nt420s 245/45r20 Tires. 2 of the 4 rims have minor curb rash the other 2 perfect. Tires have about 50% thread left. Fits 2015+ edges and other Ford/Lincoln vehicles.
  5. hi there just wanted to introduce my new to me 2016 ford edge sport with 25k miles. I just had it lowered with H&R springs and I am very pleased. Next upgrade will be the stereo not sure when.
  6. Here is some photos of my 2016 edge sport lowered with H&R springs.
  7. One of us (!) left the dashcam on while our Edge sat unused for two weeks. In that amount of time, the battery (less than a year old) drained completely, so completely that the instrument panel wouldn't light, couldn't move the gear shift out of park, etc. Dead dead dead. A jump starter just made the starter solenoid click, wouldn't crank. A long overnight charge resuscitated the battery, everything's worked fine for a few weeks now, EXCEPT: the A/C turns on automatically on engine start about 75% of the time, that's after I've made absolutely certain to turn it off before killing the engine. Is that as weird as it seems to me? Or am I so unaware that it's done it all its life and I just haven't noticed?? Thanks for any help, Jim
  8. Kona11Edge

    For Sale 2011 Ford Edge SEL AWD

    1 owner, non-smoker 3.5L V6 engine Intelligent All Wheel Drive with traction control Kona Blue with charcoal textlile interior 124k miles smooth shifting automatic transmission panoramic sunroof with sun shade factory trailer tow package keyless entry with panic alarm tilt, telescoping steering wheel Microsoft SYNC system with voice commands steering wheel controls cruise control Bluetooth AM/FM Radio Sirius XM Radio (subscription required) CD Player USB, SD and auxiliary inputs rear-view camera parking sensors dual zone climate control child seat LATCH anchor points power folding rear seats Weathertech floor liners, cargo area floor liner front and side airbags heated side mirrors power outlets front, middle and rear Michelin All-Season tires in good condition Full maintenance history included Located in Grand Rapids, MI $10,490
  9. Hi everyone! I'm hoping I can get some help here before having to go spend lots of money at the dealer The voice command button on my steering wheel has recently stopped working. I push it aaaaaaaaaand......nothing. The top part of the button which will redial the last number works fine and all other buttons work. Any ideas? Thanks so much! P.S All software is updated and has been since like August so I don't think it's an update issue.
  10. TSB 17-2271 2.0L/2.3L/2.7L EcoBoost, 5.0L, 5.2L – Engine Oil Pressure (EOP) Sensor Oil Leak 22 December 2017 This bulletin supersedes 15-0183. Reason for update: Missing or Incorrect Applications Model: Ford 2015-2017 Edge 2015-2017 F-150 2015-2017 Mustang 2016-2017 Mustang 2016-2017 Explorer 2017 Escape Lincoln 2017 MKC Summary This article supersedes TSB 15-0183 to update the vehicle list and vehicle model years. Issue: Some 2015-2017 Edge vehicles equipped with a 2.0L/2.7L EcoBoost engine, 2015-2017 F150 vehicles equipped with a 2.7L EcoBoost or 5.0L engine, 2015-2017 Mustang vehicles equipped with a 2.3L EcoBoost, 5.0L engine, 2016-2017 Mustang equipped with a 5.2L engine, 2016-2017 Explorer vehicles equipped with a 2.3L EcoBoost engine or 2017 Escape/MKC vehicles equipped with a 2.0L EcoBoost engine may exhibit an engine oil leak. This may be due to the engine oil pressure (EOP) sensor threads leaking. Action: Follow the Service Procedure steps to correct the condition. Parts Part Number Description Quantity TA-24-B Motorcraft Thread Sealant with PTFE 1 PM-4-A Motorcraft Metal Brake Parts Cleaner 1 XO-5W20-QSP Motorcraft SAE 5W-20 Premium Synthetic Blend Motor Oil – 5.0L 1 XO-5W30-QSP Motorcraft SAE 5W-30 Premium Synthetic Blend Motor Oil – 2.0L, 2.3L, 2.7L 1 XO-5W50-QGT Motorcraft SAE 5W-50 Full Synthetic Motor Oil – 5.2L 1 Warranty Status: Eligible Under Provisions Of New Vehicle Limited Warranty Coverage Warranty/ESP coverage limits/policies/prior approvals are not altered by a TSB. Warranty/ESP coverage limits are determined by the identified causal part and verified using the OASIS part coverage tool. Labor Times Description Operation No. Time 2015-2017 Edge 2.0L, Mustang 2.3L/5.0L/5.2L, 2016-2017 Explorer 2.3L: Inspect And Reseal The EOP Includes Time To Clean Area And Check/Correct Engine Oil Level (Do Not Use With Any Other Labor Operations) 172271A 0.4 2015-2017 F150 2.7L/5.0L, 2017 Escape 2.0L: Inspect And Reseal The EOP Includes Time To Clean Area And Check/Correct Engine Oil Level (Do Not Use With Any Other Labor Operations) 172271B 0.7 2015-2017 Edge 2.7L: Inspect And Reseal The EOP Includes Time To Clean Area And Check/Correct Engine Oil Level (Do Not Use With Any Other Labor Operations) 172271C 1.4 2017 MKC 2.0L: Inspect And Reseal The EOP Includes Time To Clean Area And Check/Correct Engine Oil Level (Do Not Use With Any Other Labor Operations) 172271D 0.5 Repair/Claim Coding Causal Part: 9278 Condition Code: D8 Drive Tool Name 1/4″ Ratchet 1/4″ Torque Wrench 1/4″ 2″ Extension 1/4″ 6″ Extension 1/4″ 7 mm Socket 1/4″ 8 mm Socket 1/4″ 10 mm Socket 1/4″ Power Tool 3/8″ Ratchet 3/8″ Torque Wrench 3/8″ 15 mm Socket 3/8″ 21 mm Socket 3/8″ 3/8″ to 1/2″ Adaptor 3/8″ Torx T-30 Socket 1/2″ Ratchet 1/2″ 27 mm Socket Trim Tool Wire Brush Service Procedure 1. Inspect the EOP sensor. Does the EOP sensor exhibit an oil leak at the sensor threads? (1). Yes – proceed to Step 2. (2). No – this article does not apply. Refer to Workshop Manual (WSM), Section 303-00. 2. Remove and reseal the EOP sensor, refer to WSM, Section 303-14. Clean the area as necessary. 3. Inspect and set the engine oil level as needed. Refer to WSM, Section 303-01.
  11. Six17Bred

    Push Bumper

    Will the Setina PB450L Push Bumper attach and fit correctly without modifications to the 2008 Ford Edge Limited AWD?
  12. Thanks for the help from this forum, I quickly did a little play-by-play on wiring up my dash cam and thought I would share it here. A special thanks on getting the right fuse tap. https://www.youtube.com/watch?v=JBY78H2tXiw&feature=youtu.be (First post so sorry if I am breaking any rules)
  13. Hello Everyone, I recently picked up a 2014 Edge in January and have about 2,500 miles on the vehicle. Since I picked up this vehicle in the winter, I've had to use the defrost system to clear the front windshield and side windows. Unfortunately the system has not worked properly and I decided to see if time would fix it. It is not mid-March and since the weather is nearing 32F, I've noticed that the defrost system works great above freezing. I believe that the A/C unit is not turning on above freezing as the air temperature inside the vehicle becomes colder when the thermometer reads above 32-33 degrees Fahrenheit. But then once again the temperature drops below 32-33F outside, and the defrost stops working (no more "dry" air) and the windshield and side windows frost up very fast, literally within a matter of seconds. (I'd love to video record this but as you know, it's very dangerous while driving). So basically, do any of you have this problem or know if it is a known issue with Ford? I will be taking it to a dealership very soon as it is a very serious driving hazard. On many occasions I've had to pull over and towel off the inside glass surfaces simply to continue driving. I've tried every A/C, Temp, fan speed combination and they all seem to have minimal effects. I've manually turned the A/C button on (the Edge is the first vehicle I've owned when you hit the defrost button that the A/C "light" doesn't turn on) along with the defrost and that has no effect when the outside temperature is below 32F. This is a very frustrating issue as everything else on the Edge has been great. Thank you in advance!
  14. Ryanbai

    About tpms...

    Hey guys, is 17 Focus sts tpms able to be reprogram for 18 edge sport???
  15. I have a set of Oracle Halo lights for the 2011-2014 Ford Edge models. These are the plasma models so the ring is solid unlike the SMD models where each LED is visible, they are unopened and cost me $160, I can sell them and price match them for $25 under whatever the cheapest you can find with free shipping. I can also provide pics upon request!
  16. edge2013own99

    Trouble turning on after refuel

    I have a 2013 Ford Edge Limited with around 100k kms on it, and it seems to be running fine. Though after refuelling, the car has trouble starting up, when turning on the car, the dash will come on but the wheel will remain frozen (as in I can't turn it), after attempting to turn on the car 2-3 times, it will eventually hit a turn on where you will hear the engine cranking for 15-20 seconds and it turns on normally after this. The issue then disappears till next refuel. Any advice is appreciated.
  17. Hello, First post, just bought 2017 Ford Edge Titanium and found the driver side wipe acts oddly and stutters, stops mid cycle, but turn wipers up to high a few cycles they seem to synch up. The passenger side seems fine. Oddly enough we saw the same performance on another 2017 Edge we test drove. Please help as this is very troublesome for me. Thanks!
  18. SSM 47240 – 2016-2017 Various Vehicles – SYNC 3 Navigation Map Updates Map Upgrades are now available for 2016-2017 Ford and Lincoln vehicles built with SYNC 3 Navigation. The navigation map upgrade for SYNC 3 systems is accomplished with a Universal Serial Bus (USB) drive. The USB drive will need to contain the map data along with the Map License file; both of these files are required to complete the update. The USB drive required to perform map updates can be ordered from the Ford Electronic Service Group on the PTS OASIS Home page on-line 1878 form. The SYNC 3 navigation map upgrade is currently offered as a customer pay upgrade (non warrantable) and a dealer only installation. This navigation map upgrade only covers US/Canada/Mexico. APPLICABLE VEHICLES 2016 – 2017 CAR: CG C344N HEV 2017 CAR: PL D544 LINCOLN CONTINENTAL 2016 – 2017 CAR: DQ CD539N-EDGE 2016 – 2017 TRUCK: M2 C520 NA (ESCAPE) 2016 – 2017 TRUCK: E4 ECONOLINE 2016 – 2017 TRUCK: B7 EXPEDITION (U222) 2016 – 2017 TRUCK: UB EXPLORER 2016 – 2017 TRUCK: FC P552 F150 2016 – 2017 CAR: CT B299 MCA FNA 2016 – 2017 TRUCK: P3 FLEX (FORD C/O UTILITY) 2016 – 2017 CAR: DH C346 FOCUS FNA 2016 – 2017 CAR: C7 FUSION 2016 – 2017 TRUCK: ME C489 LINCOLN CUV 2016 CAR: LE LINCOLN MKS-SWB/LWB 2016 – 2017 TRUCK: P4 MKT (LINCOLN C/O UTILITY) 2016 – 2017 CAR: D9 U540 – LINCOLN MKX 2016 – 2017 CAR: C9 MKZ (CD533) 2016 – 2017 CAR: ZG MUSTANG (S550) 2016 – 2017 TRUCK: B5 NAVIGATOR (U228) 2017 TRUCK: FE P558 SUPER DUTY – NA 2016 TRUCK: FA P473 SUPER DUTY 2016 – 2017 CAR: PH TAURUS 2016 – 2017 CAR: PH TAURUS 2016 – 2017 CAR: HC V408 (EU) 2016 – 2017 TRUCK: TH TRANSIT V363 FNA
  19. SSM 47251 – 2015-2018 Edge/2016-2018 MKX – Remote Start Selections Grayed Out For Heated Steering Wheel/Heated Seats Some 2015-2018 Edge and 2016-2018 MKX vehicles may exhibit a concern with the remote start selections for heated steering wheel and/or heated seats grayed out in the cluster. To correct this concern, reconfigure the front controls interface module (FCIM) using As-Built Programming. Make sure you are connected to the internet when entering module programming to obtain the latest data. If the concern is still present, refer to Workshop Manual (WSM), Section 501-10A for the directed self-test for the FCIM. For claiming, use causal part 18842 and applicable labor operations in Section 11 of the Service Labor Time Standards (SLTS) Manual. APPLICABLE VEHICLES 2015 – 2018 CAR: ED CD539(APA)-EDGE 2015 – 2018 CAR: DQ CD539N-EDGE 2016 – 2018 CAR: D9 U540 – LINCOLN MKX
  20. SSM 47325 – 2015-2018 Edge, 2017-2018 F-Super Duty – Climate Controlled Seats Inoperative -Diagnostic Trouble Codes (DTC) B2729, B2730, B272A, And/Or B272B Some 2015-2018 Edge and 2017-2018 F-Super Duty vehicles may exhibit inoperative climate controlled seats. This may be due to excessive sunload on the seats causing the front seat climate control module (SCME) to set DTCs B2729, B2730, B272A, and/or B727B. Clear these codes and perform an On Demand Self-Test. If the codes do not return, the repair is complete. If the codes return, follow normal diagnostics found in Workshop Manual (WSM), Section 501-10A. APPLICABLE VEHICLES 2015 – 2018 CAR: DQ CD539N EDGE 2015 – 2018 CAR: ED CD539A EDGE 2017 – 2018 TRUCK: FE P558N SUPER DUTY
  21. SSM 47378 – 2015-2018 Various Vehicles – 2.7L/3.0L EcoBoost – Crankshaft Pulley Bolt Torque Procedure During service and repair of the 2.7L/3.0L EcoBoost achieving proper torque of the crankshaft pulley bolt is critical. Incorrect torque may allow the bolt to loosen resulting in the timing gear breaking and engine damage. Replacement of the bolt is critical to the repair. The bolt requires a 4 stage torque procedure. Hold the pulley using a universal holding tool OTC 4754 or equivalent. Stage 1: 225 Nm (166 lb.ft) Stage 2: Loosen 360° Stage 3: 35 Nm (26 lb.ft) Stage 4: 270°. Refer to the Workshop Manual (WSM) Section, 303-01. The bolt torque procedure can be found in the crankshaft front seal removal and installation procedure or in the engine assembly procedure. APPLICABLE VEHICLES 2017 – 2018 CAR: PL D544N CONTINENTAL 2017 – 2018 CAR: PL D544N CONTINENTAL 2015 – 2018 CAR: DQ CD539N EDGE 2015 – 2018 TRUCK: FC P552N F-150 2017 – 2018 CAR: C7 CD391N FUSION 2016 – 2018 CAR: D9 U540N MKX 2017 – 2018 CAR: C9 CD533N MKZ
  22. NHTSA ID Number: 10099088 Manufacturer Communication Number: TSB 17-0035 Summary SOME 2015-2017 EDGE AND 2016-2017 MKX VEHICLES MAY EXHIBIT AN EXHAUST ODOR IN THE VEHICLE WHILE THE CLIMATE CONTROL SYSTEM IS IN AUTO OR RECIRCULATION MODE. CUSTOMERS MAY INDICATE THE ODOR SMELLS LIKE SULFUR, THE EXHAUST ODORS ARE ENTERING THE VEHICLE CABIN. THIS CONCERN MAY BE MORE PRONOUNCED AFTER HARD ACCELERATION, DRIVING IN HILLY CONDITIONS AND/OR TOWING A TRAILER. WHETHER AND TO WHAT EXTENT ANY OCCUPANT OF THESE VEHICLES EXPERIENCES THE EXHAUST ODOR WILL BE AFFECTED BY DRIVING HABITS, WEATHER, AND INDIVIDUAL SENSITIVITIES. FOLLOW THE SERVICE PROCEDURE STEPS TO CORRECT THE CONDITION. Vehicles MAKE MODEL YEAR FORD EDGE 2015-2017 LINCOLN MKX 2016-2017 No details on this TSB available "freely", hope someone with access can post the additional text, if any. EDIT: Per the link provided by gg (see pdf for full pictorial/text) Exhaust Odor in the Vehicle – 2015-2017 Ford Edge & 2016-2017 Lincoln MKX TSB 17-0035 EXHAUST ODOR IN VEHICLE Publication Date: March 30, 2017 FORD: 2015-2017 Edge LINCOLN: 2016-2017 MKX ISSUE: Some 2015-2017 Edge and 2016-2017 MKX vehicles may exhibit an exhaust odor in the vehicle while the climate control system is in auto or recirculation mode. Customers may indicate the odor smells like sulfur, or the exhaust odors are entering the vehicle cabin. This concern may be more pronounced after hard acceleration, driving in hilly conditions and/or towing a trailer. Whether and to what extent any occupant of these vehicles experiences the exhaust odor will be affected by driving habits, weather, and individual sensitivities ACTION: Follow the Service Procedure steps to correct the condition. SERVICE PROCEDURE Does the customer report an exhaust odor inside the vehicle under hard acceleration, towing a trailer, driving in hilly conditions or with the climate control system in auto or recirculate? Yes – proceed to Step 2. No – this article does not apply. Check the rear doors are shut tightly and the edges are correctly aligned with the rear quarter panel. Adjust the door striker as needed. Refer to Workshop Manual (WSM), Section 501-03. Visually inspect the rear liftgate weatherstrip seal for proper seating to the body of the vehicle. Check the weatherstrip contact mark around the entire liftgate to make sure the liftgate is correctly aligned. Reposition the liftgate as required to obtain a proper seal. Refer to WSM, Section 501-03. Make sure the liftgate drain plugs are installed correctly on the liftgate. Reposition as required. MKX (Figure 1) liftgate drain plugs Figure 1 – 17-0035 Edge (Figure 2) liftgate drain plugs Figure 2 – 17-0035 Remove the left and right rear lamp assemblies. Refer to WSM Section 417-01. Inspect the horizontal and vertical surfaces of the rear tail lamp assembly mounting area for holes or gaps in the body sealer. If any holes or gaps are found, seal with Motorcraft® Seam Sealer or equivalent. Verify all rear tail lamp assembly body plugs, plastic anchor nuts and wiring grommets are fully seated against the body. (Figures 3 – 4) tail lamp assembly body plugs Figure 3 – 17-0035 tail lamp assembly body plugs Figure 4 – 17-0035 On the MKX, remove the right and left rear quarter panel moulding. Refer to WSM, Section 501-08. Remove the rear bumper cover. Refer to WSM, Section 501-19. Remove the right and left rear quarter panel inner wheel liner. (Figure 5) inner wheel liner Figure 5 – 17-0035 Inspect the entire length of the joined inner fender panels for large, obvious panel gaps or body sealer gaps. Closely inspect for gaps in the following areas. If any gaps are found, seal with Motorcraft® Seam Sealer or equivalent. Lower arch edge. Upper edge of the wheel arch. (Figure 6) joined inner fender panels Figure 6 – 17-0035 Upper wheel arch area, from the back, where the outer and inner body panels meet. (Figure 7) outer and inner body panels meet Figure 7 – 17-0035 Check that all rear body plugs and plastic anchor nuts located beneath the bumper cover are fully seated against the body. (Figure 8) rear body plugs Figure 8 – 17-0035 Make sure the two plastic pushpins used to attach the sound insulation piece to the lower edge of the body are fully seated. (Figure 9) two plastic pushpins Figure 9 – 17-0035 Inspect the rear liftgate and verify that all four plastic license plate anchor nuts have been installed correctly. (Figure 10) plastic license plate anchor nuts Figure 10 – 17-0035 Raise the vehicle on the hoist and verify that all underbody plugs and grommets are fully seated. (Figure 11 – 12) underbody plugs and grommets Figure 11 – 17-0035 underbody plugs and grommets Figure 12 – 17-0035 Prepare the vehicle for a cabin pressurization test. Use masking tape to cover all air extractors and any open bolt holes located behind the rear bumper cover. (Figure 9) Cover the license plate anchor nuts by installing the license plate screws or tape over them. After waiting 1 hour since the last seam sealer application to allow for dry time, start the vehicle, set the climate control to fresh air mode and set blower speed to maximum. Close all doors and windows. Using soapy water in a spray bottle, spray soapy water at suspected leak points on the vehicle. Note all leak areas identified by the presence of air bubbles. Inspect the tail lamp openings and check for leaks at the seams, in the body sealer, and around plastic grommets and mounting nuts. (Figure 13) tail lamp openings Figure 13 – 17-0035 Inspect the area of the liftgate that meets the tail lamps for air leaks along the panel seams. (Figure 14) area of the liftgate that meets the tail lamps Figure 14 – 17-0035 Check for air leaks at all rear side body plugs, liftgate, grommets and pushpins. (Figures 15 – 16) rear side body plugs, liftgate, grommets and pushpins Figure 15 – 17-0035 rear side body plugs, liftgate, grommets and pushpins Figure 16 – 17-0035 For the Edge, check for air leaks around the liftgate release switch housing and release switch located at the top of the housing. (Figure 17) liftgate release switch housing Figure 17 – 17-0035 Closely check all body seams and body sealer applications located behind the rear bumper cover for air leaks, especially near the extractor vents. (Figure 18) behind the rear bumper cover Figure 18 – 17-0035 Check the rear inner fender panel seams and body sealer applications for air leaks, especially at the top of the wheel arch and at the lower edges. (Figure 7) Raise the vehicle and inspect the entire upper and lower seams around the spare tire well for sealer gaps and air leaks. (Figure 19) spare tire well Figure 19 – 17-0035 Check the left and right boxed sections located at the rear underside of the vehicle for leaks at the seams and at any body plugs or grommets. Thoroughly check the rest of the rear underside of the vehicle for air leaks. (Figures 20 – 21) rear underside of the vehicle Figure 20 – 17-0035 rear underside of the vehicle Figure 21 – 17-0035 Turn off the engine and climate control. Clean and dry all leak areas noted earlier. Seal all observed leaks as necessary using Motorcraft® Seam Sealer or equivalent. Example of resealed spare tire well. (Figure 22) resealed spare tire well Figure 22 – 17-0035 Example of resealing along lower right rear of vehicle. (Figure 23) resealing along lower right rear of vehicle Figure 23 – 17-0035 Example of lower box seams and body plugs. (Figure 24) lower box seams and body plugs Figure 24 – 17-0035 Edge air leak identified at the liftgate switch. Remove and reseal the liftgate switch. Refer to WSM, Section 501-14. Remove the liftgate switch. Apply a thin bead of Motorcraft® Seam Sealer or equivalent around the outer edge of the liftgate switch. (Figure 25) outer edge of the liftgate switch Figure 25 – 17-0035 Reinstall the liftgate switch. Inspect the liftgate switch from the bottom to verify no seam sealer has spilled out onto the switch. Clean as necessary. (Figure 26) liftgate switch Figure 26 – 17-0035 Remove all installed masking tape. Verify the air extractors are not deformed. Replace the air extractor if it is damaged or warped. Reinstall the rear bumper cover. Refer to WSM, Section 501-19. Reinstall the rear tail lamp assemblies. Refer to WSM, Section 417-01. Reinstall the right and left rear quarter panel splash shields and wheel opening trim moldings. Refer to WSM, Section 501-08. Remove liftgate spoiler. Refer WSM, Section 501-08. Remove and discard the original spoiler retainer clips with foam clip seals. Install new spoiler retainer clips with foam seals. (Figure 27) spoiler retainer clips with foam seals Figure 27 – 17-0035 Seal the water hose at the tower foam with Motorcraft® Seam Sealer or equivalent. Tower seal for Edge. (Figure 28) Tower seal for Edge Figure 28 – 17-0035 Tower seal for MKX. (Figure 29) Tower seal for MKX Figure 29 – 17-0035 Before reinstalling the spoiler, check all of the spoiler retainer clip holes in the liftgate are flat. Use a plastic head hammer or a block of wood to flatten any clip holes that might have been raised during spoiler removal. Reinstall the spoiler. Once installed, the spoiler tower seal and foam strip will compress around the rear washer hose and wiring. Reprogram the heating ventilation air conditioning (HVAC) module to the latest calibration using IDS release 104.05 or higher. Make sure you are connected to the internet when entering module programming to obtain the latest updates. Calibration files may also be obtained at www.motorcraftservice.com. When reprogramming the HVAC, IDS will have additional questions which will require a yes response to reprogram the module. Obtain Locally Part Number Part Description 164-R4901 PVC (Soft Foam) Strips – Rotunda Squeak and Rattle Repair Kit PART NUMBER PART NAME EM2Z-61280B62-CA Grille – Air Inlet TA-2-B Motorcraft® Seam Sealer W716328-S300 Spoiler Trim Pin OPERATION DESCRIPTION TIME MT170035 Use SLTS Operations If Available; Claim Additional Diagnosis Or Labor Performed As Actual Time Actual Time WARRANTY STATUS Eligible Under Provisions Of New Vehicle Limited Warranty Coverage. Warranty/ESP coverage limits/policies/prior approvals are not altered by a TSB. Warranty/ESP coverage limits are determined by the identified causal part and verified using the OASIS part coverage tool. DEALER CODING BASIC PART NO. CONDITION CODE 61280B62 42 TSB 17-0035_Exhaust Odor in Vehicle 2015+ Edge MKX.pdf
  23. Blake Willis Ehret

    2012 Edge Ecoboost Stutter

    Basic Info 2012 Ford Edge SEL FWD 2.0L Ecoboost 116xxx Miles Tow Package 3rd owner 245/50/R20 Spark notes on the story: Purchased early January 2017 With the known DOOR AJAR issue. Took to dealer for this repair and asked for any recommended service and I requested a transmission fluid change as well. Dealer advised not to change Transmission fluid as "it may actually cause more problems" but advised on a spark plug change. According to dealer they did an inspection on everything else (fluids,Belts,timing, Filters ETC) and it all appeared to be fine. But I'm no mechanic so how the hell do I know. Replaced the plugs (for an outrageous cost might I add seeing as the 2.0 only needs 4 at 3$ a plug) and the door ajar issue running me about $475. Now the engine has started to stutter a bit but only at low RPM. Almost feels to me like the engine may be misfiring on one cylinder but not all of the time and only when I am stepping on the gas lightly. so far no engine lights or warnings. and it seems to be running perfect at higher rpm and highway speeds. typically i experience this issue in the morning when i first start driving the car and keep in mind it had been strange weather here in KY all the way from 20 degrees to 65 in the last week or so. I had mentioned in a previous post that i had thought this may be turbo lag but someone dismissed that theory. Any help would be appreciated. Best Regards, B
  24. I'm going to apologize right off the bat if I suck at searching and couldn't find another post that answers this.. Has anyone in Canada, who has a 2013 edge with DRLs as the headlights, successfully installed HIDs that do not flicker when DRLs are active? Anyone in Canada with a 2013 edge install LED headlights (also function as DRLs during the day, full lights at night)? I'm looking around at a few places but most are located in the US and shipping costs are about half the cost of the kits. If I go through something like Amazon, they tend to be cheaper quality it seems. Any recommendations, tips, etc.. ? Thanks in advance!
  25. spacetanker

    Register Ford Water Pump Design Issues

    I've just encountered the dreaded water pump issue and am facing the prospect of potentially needing a new engine. That said, I'm in good company judging from this and other forums, I'd like to encourage those who have encountered this problem to register your issues with the NHTSA and Ford. It is likely nothing will come from this but silence ensures complacency. We all know that water pumps are maintenance items, but Ford managed to turn a repair of a few hundred dollars into something that costs well over a thousand dollars...IF you happen to catch it before it destroys the engine! Thank you for your support! Included in my NHTSA complaint 11098462: I own a 2011 Ford Edge Limited with a 3.5L, 6 cylinder engine. The vehicle has been faithfully maintained since I purchased it at ~30,000 miles. On 5/25/2018 while driving out-of-state and with approximately 120,000 miles the vehicle began exhibiting symptoms of stalling at stops and while parking; there were no warning lights or indications of trouble. Pulling off the road I inspected the automatic transmission fluid first, since that seemed the most-likely culprit. During this check I overheard a lot of noise as hot coolant was being ejected into the coolant overflow reservoir and it was while the car was parked that the overheat indicator first sounded. After shutting off the engine I noticed water on the pavement under the vehicle. I arranged for the vehicle to be towed to a Ford dealership where it was determined the coolant pump had failed. Though completely without symptoms until the final few minutes, because the pump is driven by the engine's timing chain, enough damage had been done that a significant amount of coolant had entered the engine. The engine would start, but pressures in cylinders 2 and 4 were compromised and unknown other damage had occurred. The Ford service advised that the pump replacement would cost on the order of $2,000 and that life-expectancy for the part was 150,000 miles - two numbers that seem incongruous by themselves for a maintenance item. In addition, the absence of a cooling system warning facilitated driving the vehicle while catastrophic damage was caused to the engine. Not Included in Complaint: In the days since I have read numerous other complaints from owners of vehicles equipped with this engine who have also suffered a loss due to this inferior design. Ford should be required to make owners aware of this issue, caution them to vigilantly monitor coolant temperature, the level of coolant in the overflow reservoir and the presence of fluid at the weep hole (also very difficult to observe). Ford should also install a sensor on the coolan recovery tank to warn operators of low coolant levels and greatly improve the life expectancy of the water pump, given the complexity and expense involved in maintenance.
×
