Hello, do you have wiring diagram and rest of the component location diagrams? -
I was able to to finalize it last weekend. Each radar must be connected to MS can, power and gnd. Indicator led pins are in mirror connectors. Activation in IPC and door modules. Works perfectly.
-
Otomar changed their profile photo
-
Thank you for link. There is useful info but no wiring.
-
I am adding russina blis scheme for Mondeo MK5. Edge will be same pr similar. No body has access to Ford Wiring database?
-
Yes, my car is without unfortunatelly. I did this modification on Focus MK3,5, it is quite simple but wiring is needed. It seems that wiring is same as on Smax or Mondeo MK5.
-
Hello, do you have wiring diagram for Blind spot detection system? I have EU Edge 2017. Part numbers for brackets and radars appreciated as well. Thank you Edit: Most probably these part numbers: Radar: FT4T14D453AD or JR3T14D453CA (newer version, from 2017, according to the some discussion about Mondeo MKV more precise) Bracket: FT4T14D189A
