2012 Edge 3.5 L wiring question


sundance55343

Recommended Posts

Squirrels got in my engine bay and chewed the wiring to one of my coil over plug units as well as two wires going to two injectors.



Fortunately they're on the front of the engine facing the radiator.



My question is on the far right coilover plug connector. I need to know what colors go where on the plug part that connects to the coil. It came with two purple wires, one is lighter purple. The other is darker purple.



Looking down on the engine. I need to know which purple wire goes on the left and what goes on the right.



I've looked everywhere including my Haynes manual and their wiring diagrams don't include the engine bay.



So if anybody knows or has photos of the connector going to that cylinder which is again looking at the engine from the radiator the far right coil



Thank you in advancePXL_20251018_200208165.thumb.jpg.0b73bae00dde5b13e6f8f8c664bf963d.jpg
