Power steering pump noise after pressure hose replacement and bleeding


Recommended Posts

Hello Everyone,



I own a 2013 Edge SEL AWD with 135 000km that I bought used with 108000km at the local ford dealership about 18 months ago.

They told me that the steering rack was changed under a recall.



Last week it started leaking power steering fluid, and after taking a look I discovered that the pressure hose was rusted and leaked near the rack.

It was missing little fluid, and I drove less than 10km in that situation.

I've looked through the following posts and the available videos on Youtube on this subject, and changed the hose.



https://www.fordedgeforum.com/topic/18265-power-steering-leak/

https://www.fordedgeforum.com/topic/7545-power-steering-leak/
https://www.fordedgeforum.com/topic/12767-how-to-change-high-pressure-power-steering-line-on-2007-edge/



One mishaps that happened was that I went looking for the banjo bolt torque, at the same time that my helper came to the garage, and completely forgot to torque the banjo bolt before putting in fluid and doing the bleeding process (slowly turning left and right before bump stop). After a couple seconds I realized that it was spilling fluid on the floor, not that much more than a cup or two. I then cleaned the mess and torqued the bolt to 55Nm.



Now, after filling and bleeding the system multiple times, twice yesterday, twice today, the pump still makes noise. Mostly when there is a light press on the accelerator, like when turning from a stop sign.



Earlier this afternoon, I tried the flush method provided by Mactfordedge on Youtube (https://www.youtube.com/watch?v=OOCEj3R7KIM ), and I believe that it might have helped slightly, but there is still a problem.



The fluid doesn't seem to have any bubbles, the color is great, and the level is right.

Do you think that my steering pump needs to be replaced?



Thank you very much for your help.

Best regards,

Rob

Link to comment
Share on other sites

Thank you for the fast response.

I used Motomaster low viscosity ATF, Mercon LV approved.

https://www.canadiantire.ca/en/pdp/motomaster-multi-vehicle-low-viscosity-atf-0281525p.html

I could probably change it to your recommendation.



However, I don't see any easy way of replacing completely the fluid to make sure that no motomaster oil is still present. I've seen one video of someone disconnecting a return line, but I'm not too sure about doing that.

Maybe removing the belt and turning the pump by hand would be less risky.

Link to comment
Share on other sites

The baster method is just fine, 100% replacement is not needed.  IDK the quality of the Motomaster, but it is probably ok.  But some fluids ARE better than others, and the Valvoline just might make the difference.  I would give it a go.



Good idea to check tensioner and belts now that you mention it :)  You don't have enough mileage on your Edge for those items to have a problem, but you never know!

Link to comment
Share on other sites

Thanks for the info.

I think that I will change the pump since I currently have time, and it's not that expensive on Rockauto.



I've ordered a power steering pump and belts(since I'll be taking them off).

I'll probably change the Motomaster fluid to Valvoline when replacing the pump.

  • Like 1
Link to comment
Share on other sites

Quick update.

After changing the pump and bleeding, it still makes noise. Mostly when turning from a stop.

I've used the Motomaster fluid, since it's what I had on hand.

I have trouble finding Valvoline Synthetic MaxLife fluid locally. Is there any alternative to the valvoline? I can easily have Castrol https://www.canadiantire.ca/en/pdp/castrol-transmax-full-synthetic-multi-vehicle-atf-0289195p.html#srp



My current options are the following:

-look for pinch on the new pressure line: done, no pinch found. I'll try to release the brackets to see if they apply restriction on the line.

-replace the banjo bolt, new line didn't have a new one

-change fluid to synthetic (Valvoline, Castrol)

-take an appointment at my local dealer



Currently, my most plausible guess would be the new pressure line. With the old one and enough fluid, it wouldn't do any noise.

Otherwise, it could be a contamination that got into the system, perhaps the rack itself.



Link to comment
Share on other sites

  • 9 months later...

Well the power steering issue disappeared when I changed my edge for a 2019 F-150 3.5 XTR.




In the end, the pressure hose was new, the dealer changed the banjo bolt and I did a bleeding and the noise was still there.

It might have been the steering rack.

I'm sorry that I can't give you a more helpful answer.

Link to comment
Share on other sites

  • 2 weeks later...

Ok so we have a 2012 Ford Edge, and after we had the high pressure power steering hose changed,  due to leaks under car,  the car had a very subtle but irritating whine at low rpms or while turning at a light or stop sign. The whine would get louder as we accelerated. So I searched for the answers and took it back to the shop and the ASE certified mechanics couldn’t tell me what was wrong they started pointing the pump was bad but I didn’t buy that. So in the end I ordered a factor “Motor craft Ford OEM hose” once I replaced it and put “Motor Craft Mercon V” in the power steering system. No more whine! Smooth quite drive now.
If your experiencing this ask the shop guys if they used OEM parts or not.

Hope this helps.

Link to comment
Share on other sites

  • 1 month later...




On 4/22/2019 at 8:48 AM, thunder_rob said:

Can you reply as to the procedure you used to change the pump? It looks like a PITA.

Thanks,



Jim

On 4/22/2019 at 8:48 AM, thunder_rob said:



Quick update.

After changing the pump and bleeding, it still makes noise. Mostly when turning from a stop.

I've used the Motomaster fluid, since it's what I had on hand.

I have trouble finding Valvoline Synthetic MaxLife fluid locally. Is there any alternative to the valvoline? I can easily have Castrol https://www.canadiantire.ca/en/pdp/castrol-transmax-full-synthetic-multi-vehicle-atf-0289195p.html#srp



My current options are the following:

-look for pinch on the new pressure line: done, no pinch found. I'll try to release the brackets to see if they apply restriction on the line.

-replace the banjo bolt, new line didn't have a new one

-change fluid to synthetic (Valvoline, Castrol)

-take an appointment at my local dealer



Currently, my most plausible guess would be the new pressure line. With the old one and enough fluid, it wouldn't do any noise.

Otherwise, it could be a contamination that got into the system, perhaps the rack itself.





Link to comment
Share on other sites

thunder_rob:

On 4/16/2019 at 9:42 AM, thunder_rob said:

Thanks for the info.

I think that I will change the pump since I currently have time, and it's not that expensive on Rockauto.



I've ordered a power steering pump and belts(since I'll be taking them off).

I'll probably change the Motomaster fluid to Valvoline when replacing the pump.



Can you reply as to the procedure you used to change the pump? It looks like a PITA.

Link to comment
